Описание

Welcome to our global lithium battery store.



Battery Parameters:

Battery Model: 36V 24Ah
Rated capacity (ah): 24Ah
Rated voltage (V): 36 V
Resistance of the source of cells (MΩ): about 20 PTO)
Technical description: 3.7 V 5ah / 21700 Cell
Cell combination: 3-parallel 10-series
Battery size: 75 * 75 * 225mm
Number of cells (parallel * series): 30 pcs.
Discharge voltage (V): 30 +/- 1 V
Charge voltage (V): 42 V
Rated discharge current (a): 25а
Instantaneous maximum discharge current (a): 70A
Maximum Continuous Discharge Current (A): 25a
Charge mode: CC / CV
Standard charge current (A): 2A
Charging time under Standard charge current: 4 h
Maximum Continuous Current Charge (A): 5A
Charging time with fast current charging: 2 h
Charge temperature range: 0-45 ° c
Range of discharge temperature: -20-60 ° c
Battery weight about: 1.6kg


Parts included:

1. 36 V 24Ah lithium battery, built in 25a BMS.
2. 42V 2A Lio ion Battery Charger




36V Electric bicycle Battery Built-in 25A BMS 10S3P 24Ah 21700 bateria 36v lithium batteries for scooter e bike Fast delivery
